ST26C31BTR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 ST26C31 Cut Tape (CT) RS422RS485 interface driver 5V 0.000001A 1mm 11ns
PDF
/
Buying Options
Total Price: USD $1.78
Unit Price: USD $1.7776
≥1 USD $1.7776
≥10 USD $1.59632
≥100 USD $1.506208
≥500 USD $1.283392
≥1000 USD $1.205037
≥3000 USD $1.054398
Inventory: 16558
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16

Technical

Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Driver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ST26C31
Pin Count 16
Operating Supply Voltage 5V
Power Supplies 5V
Nominal Supply Current 2mA
Output Characteristics 3-STATE
Differential Output YES
Protocol RS422, RS485
Input Characteristics STANDARD
Number of Drivers/Receivers 4/0
Driver Number of Bits 4
Transmit Delay-Max 11 ns
Out Swing-Min 2 V
High Level Input Current-Max 0.000001A
Number of Transmitters 4

Dimensions

Height 1mm
Length 5mm
Width 4.4mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
