ST232ABWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 ST232 Cut Tape (CT) RS232 interface transceiver 5V 1.5mA 7.5mm 500ns
PDF
/
Inventory: 4606
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Transceiver
Terminal Finish NICKEL PALLADIUM GOLD
Subcategory Line Driver or Receivers
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ST232
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Interface RS-232
Nominal Supply Current 1.5mA
Data Rate 400kbps
Differential Output NO
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 2/2
Driver Number of Bits 2
Duplex Full
Receiver Hysteresis 500mV
Number of Transceivers 1
Receive Delay-Max 500 ns
Transmit Delay-Max 3500 ns
Number of Receivers 2
Dimensions
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
