ST202EBW
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 ST202 Tray RS232 interface receiver 5V 10mA 7.5mm 230kbps
PDF
/
Inventory: 3505
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Technical
Number of Receivers 2
Number of Transceivers 1
Receiver Hysteresis 500mV
Duplex Full
Driver Number of Bits 2
Number of Drivers/Receivers 2/2
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Differential Output NO
Data Rate 230kbps
Nominal Supply Current 10mA
Interface RS-232
Power Supplies 5V
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 16
Base Part Number ST202
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Subcategory Line Driver or Receivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
