MC1489D1013TR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 MC1489 Cut Tape (CT) RESPONSE CONTROL interface transceiver 10V 0.01A 8.65mm 85ns
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.5625
≥1 USD $3.5625
≥10 USD $2.92315
≥100 USD $2.83195
≥500 USD $2.7398
≥1000 USD $2.6486
Inventory: 9815
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Number of Receivers 4
Output Low Current-Max 0.01A
Receive Delay-Max 85 ns
Number of Drivers/Receivers 0/4
Input Characteristics STANDARD
Protocol RS232
Supply Current-Max 26mA
Interface RS-232
Power Supplies 5V
Operating Supply Voltage 10V
Qualification Status Not Qualified
Pin Count 14
Base Part Number MC1489
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology BIPOLAR
Additional Feature RESPONSE CONTROL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Receiver
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Cut Tape (CT)
Operating Temperature 0°C~75°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
