ISL32272EIVZ
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
ROHS3Compliant GULL WING Driver BICMOS interface driver -40C~85C 10Mbps 5mm 3.3V
PDF
/
Buying Options
Total Price: USD $3.05
Unit Price: USD $3.0536
≥1 USD $3.0536
Inventory: 257
Minimum: 1
-
+
Technical Details
Technical
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 4
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
JESD-30 Code R-PDSO-G16
Qualification Status COMMERCIAL
Data Rate 10Mbps
Protocol RS422, RS485
Number of Drivers/Receivers 4/0
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology BICMOS
Terminal Finish MATTE TIN
Type Driver
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Operating Temperature -40°C~85°C
Dimensions
Height Seated (Max) 1.2mm
Length 5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Surface Mount YES
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
