ADM239LAQ
RoHS
/
Package 24-CDIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
R-GDIP-T24 Tube INTERNAL CHARGE PUMP; TRISTATABLE RECEIVERS RS232 interface receiver 5V 5.08mm 85C
PDF
/
Buying Options
Total Price: USD $2.81
Unit Price: USD $2.8072
≥1 USD $2.8072
Inventory: 1116
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Height Seated (Max) 5.08mm
Technical
Supply Voltage1-Nom 12V
Interface Standard EIA-232-E; V.28
Receiver Number of Bits 5
Driver Number of Bits 3
Number of Drivers/Receivers 3/5
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Differential Output NO
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
JESD-30 Code R-GDIP-T24
Pin Count 24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 3
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Additional Feature INTERNAL CHARGE PUMP; TRISTATABLE RECEIVERS
Terminal Finish TIN LEAD
Type Transceiver
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Physical
Surface Mount NO
Package / Case 24-CDIP (0.300, 7.62mm)
Mounting Type Through Hole
