USB1T11AM
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 USB1T11A Tube USB 1.1 interface transceiver 3.3V 5mA 150mg 300ns
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.5192
≥1 USD $0.5192
Inventory: 1585
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 36 Weeks
Lifecycle Status LIFETIME (Last Updated: 6 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Weight 150mg
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Termination SMD/SMT
ECCN Code EAR99
Type Transceiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number USB1T11A
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Interface Serial
Operating Supply Current 5mA
Number of Ports 2
Nominal Supply Current 5mA
Output Current 4mA
Number of Bits 1
Family USB
Data Rate 12Mbps
Output Characteristics 3-STATE
Nominal Input Voltage 2V
Output Polarity TRUE
Protocol USB 1.1
Number of Drivers/Receivers 1/1
Propagation Delay (tpd) 300 ns
Duplex Half
ESD Protection Yes
Number of Receivers 1
Dimensions
Height 1.5mm
Length 8.75mm
Width 4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
