MCP2003BT-E/MC
RoHS
RoHS compliant
RoHS compliantPackage 8-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
R-PDSO-N8 MCP2003 Tape & Reel (TR) LINbus interface receiver 12V 3mm 6000ns 20kBaud
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.836
≥1 USD $0.836
≥10 USD $0.6952
≥100 USD $0.6336
Inventory: 5982
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 2mm
Length 3mm
Height Seated (Max) 1mm
Technical
Transmit Delay-Max 4000 ns
Simplex/Duplex Half Duplex
Receive Delay-Max 6000 ns
Interface Standard ISO 17987; ISO 7637
Duplex Half
Receiver Number of Bits 1
Screening Level TS 16949
Driver Number of Bits 1
Number of Drivers/Receivers 1/1
Input Characteristics SCHMITT TRIGGER
Protocol LINbus
Differential Output NO
Data Rate 20kBaud
JESD-30 Code R-PDSO-N8
Base Part Number MCP2003
Terminal Pitch 0.5mm
Supply Voltage 12V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position DUAL
Voltage - Supply 5.5V~30V
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn) - annealed
Type Transceiver
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Package / Case 8-VFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Alternative Model
