MCP2003-E/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 MCP2003 Tube THERMAL SHUTDOWN interface driver 27V 1mA 930.006106mg 6000ns
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
≥10 USD $0.8976
≥100 USD $0.8272
Inventory: 488
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Weight 930.006106mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Transceiver
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature THERMAL SHUTDOWN
Voltage - Supply 6V~27V
Terminal Position DUAL
Number of Functions 1
Supply Voltage 12V
Base Part Number MCP2003
Pin Count 8
Output Voltage 27V
Interface LIN
Operating Supply Current 90μA
Nominal Supply Current 1mA
Output Current 200mA
Max Supply Current 1mA
Differential Output NO
Protocol LINbus
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 1/1
Receiver Number of Bits 1
Duplex Half
Receiver Hysteresis 175mV
Number of Drivers 1
Number of Transceivers 2
Receive Delay-Max 6000 ns
Transmit Delay-Max 4000 ns
Baud Rate 20 kbaud
Dimensions
Height 3.3mm
Length 9.27mm
Width 6.35mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
