MAX3491EEPD
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
Non-RoHS Compliant DIFFERENTIAL SCHMITT TRIGGER Full 1999 Transceiver -40C~85C 10Mbps 35ns 4.572mm
PDF
/
Buying Options
Total Price: USD $4.02
Unit Price: USD $4.024593
≥1 USD $4.024593
≥10 USD $3.796788
≥100 USD $3.581876
≥500 USD $3.379126
≥1000 USD $3.187852
Inventory: 1167
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 14-DIP (0.300, 7.62mm)
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 1999
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Transceiver
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 2.54mm
Base Part Number MAX3491
Pin Count 14
Operating Supply Voltage 3.3V
Supply Current-Max 2.2mA
Logic Function Receiver
Data Rate 10Mbps
Differential Output YES
Protocol RS422, RS485
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 1/1
Driver Number of Bits 1
Receiver Number of Bits 1
Duplex Full
Receiver Hysteresis 50mV
Interface Standard EIA-422; EIA-485
Transmit Delay-Max 35 ns
Output Low Current-Max 0.0025A
Number of Transmitters 1
Dimensions
Height Seated (Max) 4.572mm
Width 7.62mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
