MAX3388ECUG
RoHS
/
Package 24-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
Non-RoHS Compliant SCHMITT TRIGGER GULL WING Full Transceiver 0C~70C 2.5V 460Kbps 7.8mm
PDF
/
Inventory: 4916
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 24-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2001
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Type Transceiver
Terminal Finish Tin/Lead (Sn85Pb15)
HTS Code 8542.39.00.01
Subcategory Line Driver or Receivers
Technology CMOS
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 2
Supply Voltage 2.5V
Terminal Pitch 0.65mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number MAX3388E
Pin Count 24
JESD-30 Code R-PDSO-G24
Qualification Status Not Qualified
Power Supplies 2.5V
Supply Current-Max 1mA
Data Rate 460Kbps
Differential Output NO
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 3/2
Driver Number of Bits 3
Receiver Number of Bits 2
Duplex Full
Receiver Hysteresis 700mV
Interface Standard EIA-232; TIA-232; V.24; V.28
Dimensions
Height Seated (Max) 1.1mm
Length 7.8mm
Width 4.4mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
