MAX3244EAI
RoHS
/
Package 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
Non-RoHS Compliant SCHMITT TRIGGER GULL WING Full Transceiver -40C~85C 250kbps 10.2mm 0.000001A
PDF
/
Inventory: 2733
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2002
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type Transceiver
Terminal Finish Tin/Lead (Sn85Pb15)
HTS Code 8542.39.00.01
Subcategory Line Driver or Receivers
Technology BICMOS
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 3
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number MAX3244
Pin Count 28
JESD-30 Code R-PDSO-G28
Qualification Status Not Qualified
Supply Current-Max 1mA
Data Rate 250kbps
Differential Output NO
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 3/5
Driver Number of Bits 3
Receiver Number of Bits 5
Duplex Full
Receiver Hysteresis 500mV
Interface Standard EIA-232; TIA-232; V.24; V.28
Output Low Current-Max 0.0016A
Out Swing-Min 5 V
High Level Input Current-Max 0.000001A
Dimensions
Height Seated (Max) 1.99mm
Length 10.2mm
Width 5.29mm
Compliance
RoHS Status Non-RoHS Compliant
