MAX3096CPE
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
Non-RoHS Compliant DIFFERENTIAL SCHMITT TRIGGER 2010 Receiver Receiver 0C~70C 10Mbps 123ns 19.175mm
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3832
≥1 USD $1.3832
≥10 USD $1.13525
≥100 USD $1.09915
≥500 USD $1.064
≥1000 USD $1.02885
Inventory: 1117
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Number of Pins 16
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2010
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Receiver
Terminal Finish Tin/Lead (Sn85Pb15)
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Number of Functions 4
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number MAX3096
Pin Count 16
Operating Supply Voltage 3.3V
Interface RS-422
Nominal Supply Current 2.4mA
Data Rate 10Mbps
Protocol RS422, RS485
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 0/4
Receiver Hysteresis 45mV
Receive Delay-Max 123 ns
Number of Receivers 4
Dimensions
Length 19.175mm
Width 7.62mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
