MAX232MLP

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 20-LCC
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 Tube EXTERNAL CHARGE PUMP RS232 interface driver 5V 8.89mm 120Kbps 5V
PDF
/
Inventory: 9923
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 8.89mm
Length 8.89mm

Technical

Number of Receivers 2
Number of Transceivers 1
Receiver Hysteresis 500mV
Driver Number of Bits 2
Number of Drivers/Receivers 2/2
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Output Polarity INVERTED
Differential Output NO
Output Characteristics TOTEM-POLE
Data Rate 120Kbps
Logic Function Receiver
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 20
Time@Peak Reflow Temperature-Max (s) 20
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 240
Terminal Position QUAD
Additional Feature EXTERNAL CHARGE PUMP
Terminal Finish Tin/Lead (Sn/Pb)
Type Transceiver
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2013
Packaging Tube
Operating Temperature -55°C~125°C

Physical

Number of Pins 20
Surface Mount YES
Package / Case 20-LCC
Mounting Type Surface Mount
