MAX232EPE
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
TOTEM-POLE INVERTED Non-RoHS Compliant SCHMITT TRIGGER Transceiver -40C~85C 842mW 120Kbps 10000ns
PDF
/
Buying Options
Total Price: USD $6.17
Unit Price: USD $6.175
≥1 USD $6.175
≥10 USD $5.0673
≥100 USD $4.90865
≥500 USD $4.75
≥1000 USD $4.5923
Inventory: 1184
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Length 19.175mm
Height Seated (Max) 4.572mm
Technical
Out Swing-Min 10 V
Output Low Current-Max 0.0032A
Transmit Delay-Max 10000 ns
Receive Delay-Max 10000 ns
Interface Standard EIA-232-E; TIA-232-E; V.28; V.24
Receiver Hysteresis 500mV
Duplex Full
Receiver Number of Bits 2
Driver Number of Bits 2
Number of Drivers/Receivers 2/2
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Output Polarity INVERTED
Differential Output NO
Output Characteristics TOTEM-POLE
Data Rate 120Kbps
Supply Current-Max 10mA
Power Dissipation 842mW
Operating Supply Current 4μA
Power Supplies 5V
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T16
Pin Count 16
Base Part Number MAX232
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Subcategory Line Driver or Receivers
HTS Code 8542.39.00.01
Additional Feature EXTERNAL CHARGE PUMP
Terminal Finish Matte Tin (Sn)
Type Transceiver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2004
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
