MAX206ECWG
RoHS
/
Package 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
INVERTED Non-RoHS Compliant SCHMITT TRIGGER GULL WING Transceiver 0C~70C 5V 120Kbps 10000ns
PDF
/
Buying Options
Total Price: USD $9.5
Unit Price: USD $9.496024
≥1 USD $9.496024
≥10 USD $8.958507
≥100 USD $8.451419
≥500 USD $7.973043
≥1000 USD $7.521741
Inventory: 3564
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 24-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2009
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Type Transceiver
Terminal Finish Tin/Lead (Sn85Pb15)
HTS Code 8542.39.00.01
Subcategory Line Driver or Receivers
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 3
Supply Voltage 5V
Terminal Pitch 1.27mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX206
Pin Count 24
JESD-30 Code R-PDSO-G24
Qualification Status Not Qualified
Power Supplies 5V
Supply Current-Max 20mA
Data Rate 120Kbps
Differential Output NO
Output Polarity INVERTED
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 4/3
Driver Number of Bits 4
Receiver Number of Bits 3
Duplex Full
Receiver Hysteresis 500mV
Interface Standard EIA-232-E; TIA-232-E; V.28
Receive Delay-Max 10000 ns
Output Low Current-Max 0.0016A
Out Swing-Min 10 V
Dimensions
Height Seated (Max) 2.65mm
Length 15.4mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
