MAX205ECPG
RoHS
/
Package 24-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
INVERTED Non-RoHS Compliant SCHMITT TRIGGER Full Transceiver 0C~70C 1.14W 120Kbps 10mus
PDF
/
Buying Options
Total Price: USD $17.18
Unit Price: USD $17.18075
≥1 USD $17.18075
≥10 USD $14.09705
≥100 USD $13.6572
≥500 USD $13.2164
≥1000 USD $12.7756
Inventory: 1175
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP (0.600, 15.24mm)
Number of Pins 24
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 1997
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Type Transceiver
Subcategory Line Driver or Receivers
Max Power Dissipation 1.14W
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 245
Number of Functions 5
Supply Voltage 5V
Base Part Number MAX205
Pin Count 24
Output Voltage 9V
Operating Supply Voltage 5V
Power Supplies 5V
Interface RS-232
Number of I/O 20
Nominal Supply Current 20mA
Output Current 10mA
Propagation Delay 10 μs
Logic Function Receiver, Transceiver
Data Rate 120Kbps
Differential Output NO
Output Polarity INVERTED
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 5/5
Receiver Number of Bits 5
Duplex Full
Receiver Hysteresis 500mV
Number of Drivers 5
Number of Transceivers 1
Dimensions
Height 4.45mm
Length 32.26mm
Width 14.61mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
