LTC2870IFE#PBF
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 LTC2870 Tube Multiprotocol interface driver 130mV 0.003A 9.7mm 200ns
PDF
/
Buying Options
Total Price: USD $13.25
Unit Price: USD $13.2528
≥1 USD $13.2528
≥10 USD $12.1792
≥100 USD $11.674432
≥500 USD $10.286056
≥1000 USD $9.781235
≥3000 USD $9.150205
Inventory: 1144
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-TSSOP (0.173, 4.40mm Width) Exposed Pad
Number of Pins 28
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2010
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type Transceiver
Terminal Finish Matte Tin (Sn)
Subcategory Line Driver or Receivers
Technology CMOS
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 3
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LTC2870
Pin Count 28
Qualification Status Not Qualified
Power Supplies 3.3V
Data Rate 20Mbps
Differential Output YES
Protocol Multiprotocol
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 2/2
Driver Number of Bits 3
Receiver Number of Bits 3
Duplex Full
Receiver Hysteresis 130mV
Interface Standard EIA-232; EIA-422; EIA-485
Number of Transceivers 1
Receive Delay-Max 200 ns
Transmit Delay-Max 70 ns
Supply Voltage1-Nom 3.3V
Output Low Current-Max 0.003A
Dimensions
Length 9.7mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
