HIN202ECBZ
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
RoHS Compliant SCHMITT TRIGGER GULL WING 2000 (Type) 70C 5V 230kbps 10000ns
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.9944
≥1 USD $0.9944
≥10 USD $0.89408
≥100 USD $0.843392
≥500 USD $0.718608
≥1000 USD $0.594
Inventory: 8659
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Package / Case SOIC
Number of Pins 16
Technical
Packaging Bulk
Published 2000
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Subcategory Line Driver or Receivers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade COMMERCIAL
Interface RS-232
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Nominal Supply Current 15mA
Logic Function Receiver, Transceiver
Data Rate 230 kbps
Differential Output NO
Input Characteristics SCHMITT TRIGGER
Driver Number of Bits 2
Receiver Number of Bits 2
Receive Delay-Max 10000 ns
Transmit Delay-Max 10000 ns
Out Swing-Min 10 V
Number of Transmitters 2
Dimensions
Height 2.35mm
Length 10.5mm
Width 7.6mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
