ADM3101EACPZ-REEL
RoHS
RoHS compliant
RoHS compliantPackage 12-WFQFN Exposed Pad, CSP
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 ADM3101 Tape & Reel (TR) DUMMY VAL interface driver 3.3V 5mA 3mm 460Kbps
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9405
≥1 USD $0.9405
≥10 USD $0.7714
≥100 USD $0.74765
≥500 USD $0.72295
≥1000 USD $0.6992
≥3000 USD $0.627
Inventory: 214301
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Mounting Type Surface Mount
Package / Case 12-WFQFN Exposed Pad, CSP
Surface Mount YES
Number of Pins 12
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 12
ECCN Code EAR99
Type Transceiver
Terminal Finish Matte Tin (Sn)
Additional Feature DUMMY VAL
Subcategory Line Driver or Receivers
Technology CMOS
Voltage - Supply 3V~5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number ADM3101
Pin Count 12
Qualification Status Not Qualified
Operating Supply Voltage 3.3V
Operating Supply Current 5mA
Nominal Supply Current 5mA
Logic Function Receiver, Transceiver
Data Rate 460Kbps
Differential Output NO
Protocol RS232
Simplex/Duplex Full Duplex
Number of Transceivers 1
Interface Standard EIA-232; TIA-232; V.28
Receiver Hysteresis 400mV
Duplex Full
Receiver Number of Bits 1
Driver Number of Bits 1
Number of Drivers/Receivers 1/1
Input Characteristics SCHMITT TRIGGER
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
