TSB43DB42GHC
RoHS
RoHS compliant
RoHS compliantPackage 196-LBGA
Category Integrated Circuits (ICs) / Interface - Controllers
Description
ROHS3Compliant BOTTOM PCI BUS CONTROLLER CMOS IEEE 1394 Link Layer Controller 33MHz -20C~85C 400Mbps 15mm
PDF
/
Buying Options
Total Price: USD $12.52
Unit Price: USD $12.5224
≥1 USD $12.5224
Inventory: 712
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 15mm
Length 15mm
Height Seated (Max) 1.5mm
Technical
Bus Compatibility PCI
Standards IEEE 1394-1995, 1394a-2000
External Data Bus Width 32
Protocol IEEE 1394
Address Bus Width 32
Data Rate 400 Mbps
Clock Frequency 33MHz
uPs/uCs/Peripheral ICs Type PCI BUS CONTROLLER
Interface Parallel
Function Link Layer Controller
Base Part Number TSB43DB42
Terminal Pitch 1mm
Peak Reflow Temperature (Cel) 220
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.5V 3.3V
Technology CMOS
HTS Code 8542.31.00.01
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code 3A991.A.2
Number of Terminations 196
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tray
Operating Temperature -20°C~85°C
Physical
Weight 584.113574mg
Number of Pins 196
Surface Mount YES
Package / Case 196-LBGA
