TSB43AB23IPDTEP
RoHS
RoHS compliant
RoHS compliantPackage 128-TQFP
Category Integrated Circuits (ICs) / Interface - Controllers
Description
TSB43AB23 Tray 8542.31.00.01 PCI interface controller 3V~3.6V 14mm 158mA 400Mbps
PDF
/
Buying Options
Total Price: USD $22.81
Unit Price: USD $22.81045
≥1 USD $22.81045
≥10 USD $18.7169
≥100 USD $18.1317
≥500 USD $17.5465
≥1000 USD $16.96225
Inventory: 1354
Minimum: 1
-
+
Technical Details
Physical
Package / Case 128-TQFP
Surface Mount YES
Number of Pins 128
Weight 503.487531mg
Technical
Operating Temperature -40°C~85°C
Packaging Tray
JESD-609 Code e4
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 128
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature ALSO REQUIRES 3.3V SUPPLY
HTS Code 8542.31.00.01
Subcategory Bus Controllers
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.8V
Terminal Pitch 0.4mm
Base Part Number TSB43AB23
Function Physical Layer Controller
Power Supplies 1.833.33.3/5V
Interface PCI
Number of I/O 2
Nominal Supply Current 158mA
uPs/uCs/Peripheral ICs Type SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
Clock Frequency 24.576MHz
Data Rate 400 Mbps
Address Bus Width 32
Protocol IEEE 1394
Boundary Scan NO
Low Power Mode YES
External Data Bus Width 32
Number of Serial I/Os 3
Standards IEEE 1394-1995, 1394a-2000, OHCI, Firewire?, i.Link?
Bus Compatibility PCI
Data Transfer Rate-Max 50 MBps
Dimensions
Height Seated (Max) 1.2mm
Length 14mm
Width 14mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
