TSB42AA9APZTR
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Interface - Controllers
Description
ROHS3Compliant QUAD SERIAL IO/COMMUNICATION CONTROLLER SERIAL COMMERCIAL IEEE 1394 Link Layer Controller 49.152MHz 70C 50MBps 14mm
PDF
/
Buying Options
Total Price: USD $10.05
Unit Price: USD $10.0496
≥1 USD $10.0496
Inventory: 1046
Minimum: 1
-
+
Technical Details
Physical
Package / Case 100-TQFP
Surface Mount YES
Number of Pins 100
Weight 1.758804g
Technical
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
HTS Code 8542.31.00.01
Subcategory Bus Controllers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TSB42AA9
Function Link Layer Controller
Qualification Status Not Qualified
Operating Temperature (Max) 70°C
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 3V
Interface Parallel
uPs/uCs/Peripheral ICs Type SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
Clock Frequency 49.152MHz
Address Bus Width 3
Protocol IEEE 1394
Boundary Scan NO
Low Power Mode NO
External Data Bus Width 16
Number of Serial I/Os 1
Standards IEEE 1394-1995, 1394a-2000
Data Transfer Rate-Max 50 MBps
Dimensions
Height Seated (Max) 1.2mm
Length 14mm
Width 14mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
