TSB14AA1TPFB
RoHS
RoHS compliant
RoHS compliantPackage 48-TQFP
Category Integrated Circuits (ICs) / Interface - Controllers
Description
ROHS3Compliant QUAD SERIAL IO/COMMUNICATION CONTROLLER SERIAL CMOS IEEE 1394 Physical Layer Controller 100MHz -40C~105C 12.5MBps 7mm
PDF
/
Buying Options
Total Price: USD $6.52
Unit Price: USD $6.52058
≥1 USD $6.52058
≥10 USD $6.151488
≥100 USD $5.803294
≥500 USD $5.474807
≥1000 USD $5.164905
Inventory: 1160
Minimum: 1
-
+
Technical Details
Technical
Qualification Status Not Qualified
uPs/uCs/Peripheral ICs Type SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
Clock Frequency 100MHz
Protocol IEEE 1394
Boundary Scan NO
Low Power Mode YES
Number of Serial I/Os 1
Standards IEEE 1394-1995
Bus Compatibility PCI
Data Transfer Rate-Max 12.5 MBps
Data Encoding/Decoding Method NRZ
Function Physical Layer Controller
JESD-30 Code S-PQFP-G48
Base Part Number TSB14AA1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 3.3V
Technology CMOS
HTS Code 8542.31.00.01
Terminal Finish NICKEL PALLADIUM GOLD
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tray
Operating Temperature -40°C~105°C
Dimensions
Height Seated (Max) 1.2mm
Length 7mm
Width 7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
Physical
Surface Mount YES
Package / Case 48-TQFP
