DP83934CVUL-25

Texas Instruments
RoHS
/
Package 160-BQFP
Category Integrated Circuits (ICs) / Interface - Controllers
Description DP83934 Tube S-PQFP-G160 NRZ; BIPH-LEVEL(MANCHESTER) interface controller 4.75V~5.25V 28mm 140mA 1.25MBps
PDF
/
Buying Options
Total Price: USD $17.28
Unit Price: USD $17.28145
≥1 USD $17.28145
≥10 USD $14.1797
≥100 USD $13.73605
≥500 USD $13.29335
≥1000 USD $12.85065
Inventory: 1168
Minimum: 1
-
+

Technical Details

Physical

Package / Case 160-BQFP
Surface Mount YES

Technical

Operating Temperature 0°C~70°C
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Data Encoding/Decoding Method NRZ; BIPH-LEVEL(MANCHESTER)
Data Transfer Rate-Max 1.25 MBps
Bus Compatibility NS32532; 68030; 68020
Standards 10 Base-T PHY
Number of Serial I/Os 2
External Data Bus Width 32
Low Power Mode NO
Boundary Scan NO
Protocol Ethernet
Address Bus Width 32
Current - Supply 140mA
Clock Frequency 25MHz
Interface Parallel
Function Controller
JESD-30 Code S-PQFP-G160
Base Part Number DP83934
Reach Compliance Code unknown
Terminal Pitch 0.65mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 4.75V~5.25V
Technology CMOS
HTS Code 8542.31.00.01
Number of Terminations 160

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Width 28mm
Length 28mm
Height Seated (Max) 3.7mm
