USB5826/KD
RoHS
RoHS compliant
RoHS compliantPackage 100-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Controllers
Description
USB5826 Tube S-XQCC-N100 2016 interface controller 1.2V 3.3V 12mm 625MBps 0C~70C
PDF
/
Buying Options
Total Price: USD $4.29
Unit Price: USD $4.289244
≥1 USD $4.289244
≥10 USD $3.735201
≥30 USD $3.406976
≥100 USD $3.074812
≥500 USD $2.921203
≥1000 USD $2.852932
Inventory: 1251
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 100-VFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2016
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.31.00.01
Technology CMOS
Voltage - Supply 1.2V 3.3V
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 1.2V
Terminal Pitch 0.4mm
Base Part Number USB5826
JESD-30 Code S-XQCC-N100
Function Hub Controller
Interface I2C, SPI
uPs/uCs/Peripheral ICs Type BUS CONTROLLER, UNIVERSAL SERIAL BUS
Protocol USB
Screening Level TS 16949
Standards USB 3.1
Data Transfer Rate-Max 625 MBps
Dimensions
Height Seated (Max) 0.9mm
Length 12mm
Width 12mm
Compliance
RoHS Status ROHS3 Compliant
