USB5537BI4100AKZETR
RoHS
RoHS compliant
RoHS compliantPackage 72-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Controllers
Description
USB5537B Tape & Reel (TR) S-XQCC-N72 2012 interface controller 1.253.3V 10mm 1.5Mbps 85C
PDF
/
Inventory: 6725
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1mm
Technical
Bus Compatibility I2C; SMBUS
Standards USB 3.0
Protocol USB
Data Rate 1.5 Mbps
Clock Frequency 25MHz
uPs/uCs/Peripheral ICs Type BUS CONTROLLER, UNIVERSAL SERIAL BUS
Number of Ports 4
Supply Voltage-Min (Vsup) 1.22V
Temperature Grade INDUSTRIAL
Power Supplies 1.253.3V
Supply Voltage-Max (Vsup) 1.31V
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Function Hub Controller
JESD-30 Code S-XQCC-N72
Base Part Number USB5537B
Terminal Pitch 0.5mm
Supply Voltage 1.25V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Subcategory Bus Controllers
Additional Feature ALSO OPRATES AT 3.3 V SUPPLY
Number of Terminations 72
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Published 2012
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 72-VFQFN Exposed Pad
