USB5534B-6080JZXTR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Controllers
Description
USB5534B Tape & Reel (TR) e3 2010 interface controller 1.25V 3.3V 9mm 625MBps 0C~70C
PDF
/
Buying Options
Total Price: USD $8.86
Unit Price: USD $8.8597
≥1 USD $8.8597
≥10 USD $7.27035
≥100 USD $7.04235
≥500 USD $6.8153
≥1000 USD $6.58825
Inventory: 1968
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9mm
Length 9mm
Height Seated (Max) 1mm
Technical
Data Transfer Rate-Max 625 MBps
Bus Compatibility I2C; SMBUS; SPI; VBUS
Standards USB 3.0
Protocol USB
uPs/uCs/Peripheral ICs Type BUS CONTROLLER, UNIVERSAL SERIAL BUS
Number of Ports 4
Operating Supply Voltage 5V
Function Hub Controller
Base Part Number USB5534B
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 1.25V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.25V 3.3V
Technology CMOS
Additional Feature ALSO OPERATES AT 3.3 V
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 64
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Weight 206.29948mg
Number of Pins 64
Surface Mount YES
Package / Case 64-VFQFN Exposed Pad
Supply Chain
Factory Lead Time 7 Weeks
