USB5534B-6080JZX
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Controllers
Description
USB5534B Tray e3 2011 interface controller 1.25V 3.3V 950mum 0C~70C
PDF
/
Buying Options
Total Price: USD $6.75
Unit Price: USD $6.7496
≥1 USD $6.7496
≥10 USD $5.6232
≥100 USD $5.434
Inventory: 323
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Package / Case 64-VFQFN Exposed Pad
Number of Pins 64
Weight 206.29948mg
Technical
Operating Temperature 0°C~70°C
Packaging Tray
Published 2011
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature ALSO OPERATES AT 3.3 V
Technology CMOS
Voltage - Supply 1.25V 3.3V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.25V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number USB5534B
Function Hub Controller
Operating Supply Voltage 5V
Number of Ports 4
uPs/uCs/Peripheral ICs Type BUS CONTROLLER, UNIVERSAL SERIAL BUS
Protocol USB
ESD Protection Yes
Standards USB 3.0
Bus Compatibility I2C; SMBUS
Dimensions
Height 950μm
Length 9.1mm
Width 9.1mm
Compliance
RoHS Status ROHS3 Compliant
