USB3503-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Controllers
Description
USB3503 Tray e3 1996 interface controller 1.8V 950mum 24mA 1Mbps
PDF
/
Buying Options
Total Price: USD $4.13
Unit Price: USD $4.1272
≥1 USD $4.1272
≥10 USD $3.4408
≥100 USD $3.333
Inventory: 698
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5.1mm
Length 5.1mm
Height 950μm
Technical
Bus Compatibility I2C
Standards USB 2.0
ESD Protection Yes
Number of Transceivers 1
Dual Supply Voltage 1.8V
Protocol USB
Data Rate 1 Mbps
Clock Frequency 52MHz
uPs/uCs/Peripheral ICs Type BUS CONTROLLER, UNIVERSAL SERIAL BUS
Operating Supply Current 24mA
Min Supply Voltage 2.8V
Max Supply Voltage 3.6V
Operating Supply Voltage 3.3V
Function Hub Controller
Base Part Number USB3503
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Published 1996
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
