USB2502-AEZG
RoHS
RoHS compliant
RoHS compliantPackage 36-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Controllers
Description
USB2502 Tray e3 2007 interface controller 1.62V~3.6V 850mum 100mA 480Mbps
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.10675
≥1 USD $1.10675
≥10 USD $0.9082
≥100 USD $0.8797
≥500 USD $0.8512
≥1000 USD $0.8227
Inventory: 43641
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6mm
Length 6mm
Height 850μm
Technical
Standards USB 2.0
Number of Transceivers 3
Dual Supply Voltage 3.3V
Protocol USB
Data Rate 480 Mbps
uPs/uCs/Peripheral ICs Type BUS CONTROLLER, UNIVERSAL SERIAL BUS
Number of Ports 2
Operating Supply Current 100mA
Operating Supply Voltage 3.3V
Function Hub Controller
Base Part Number USB2502
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Terminal Position QUAD
Voltage - Supply 1.62V~3.6V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 36
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Weight 92.589543mg
Number of Pins 36
Package / Case 36-VFQFN Exposed Pad
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
