MCP2140T-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Controllers
Description
MCP2140 Tape & Reel (TR) R-PDSO-G18 2003 interface controller 3V~5.5V 11.5316mm 2.2mA -40C~125C
PDF
/
Buying Options
Total Price: USD $2.43
Unit Price: USD $2.4288
≥1 USD $2.4288
Inventory: 1120
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Package / Case 18-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2003
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8542.39.00.01
Technology CMOS
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP2140
JESD-30 Code R-PDSO-G18
Function Controller
Operating Supply Voltage 5.5V
Interface UART
Nominal Supply Current 2.2mA
Protocol IRDA?
Telecom IC Type TELECOM CIRCUIT
Dimensions
Height Seated (Max) 2.6416mm
Length 11.5316mm
Width 7.493mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
