LAN7850/8JX
RoHS
RoHS compliant
RoHS compliantPackage 56-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Controllers
Description
ROHS3Compliant QUAD SERIAL IO/COMMUNICATION CONTROLLER LAN CMOS Ethernet Bridge, USB to Ethernet 25MHz 0C~70C 60MBps 183mA
PDF
/
Buying Options
Total Price: USD $6.78
Unit Price: USD $6.7848
≥1 USD $6.7848
≥10 USD $5.6584
≥100 USD $5.467
Inventory: 259
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 8mm
Length 8mm
Height Seated (Max) 1mm
Technical
Data Transfer Rate-Max 60 MBps
Bus Compatibility USB
Standards USB 2.0
Low Power Mode YES
Boundary Scan YES
Protocol Ethernet
Supply Current-Max 183mA
Clock Frequency 25MHz
uPs/uCs/Peripheral ICs Type SERIAL IO/COMMUNICATION CONTROLLER, LAN
Interface USB
Function Bridge, USB to Ethernet
JESD-30 Code S-PQCC-N56
Base Part Number LAN7850
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.8V 3.3V
Technology CMOS
HTS Code 8542.31.00.01
Number of Terminations 56
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2017
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 56-VFQFN Exposed Pad
Supply Chain
Factory Lead Time 8 Weeks
