TP3064BN
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - CODECs
Description
Contains Lead Through Hole ROHS3Compliant CMOS IC CODEC PCM, Filter 0C~70C 24.325mm 4.75V 8b
PDF
/
Buying Options
Total Price: USD $2.22
Unit Price: USD $2.21825
≥1 USD $2.21825
≥10 USD $1.8202
≥100 USD $1.7632
≥500 USD $1.7062
≥1000 USD $1.65015
Inventory: 14204
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 20-DIP (0.300, 7.62mm)
Number of Pins 20
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Type PCM, Filter
Terminal Finish NICKEL PALLADIUM GOLD
Subcategory Codecs
Technology CMOS
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Base Part Number TP3064
Power Supplies +-5V
Interface 2-Wire, Serial
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Data Interface Serial
Voltage - Supply, Analog 4.75V~5.25V
Voltage - Supply, Digital 4.75V~5.25V
Number of D/A Converters 1
Resolution (Bits) 8 b
Sigma Delta No
Number of ADCs / DACs 1 / 1
Filter YES
Companding Law MU-LAW
Neg Supply Voltage-Nom -5V
Dimensions
Height Seated (Max) 5.08mm
Length 24.325mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
