TLV320AIC20CPFBR
RoHS
RoHS compliant
RoHS compliantPackage 48-TQFP
Category Integrated Circuits (ICs) / Interface - CODECs
Description
Contains Lead Surface Mount ROHS3Compliant CMOS IC CODEC Voice-Band 0C~70C 26ksps 137.410139mg 1.65V
PDF
/
Buying Options
Total Price: USD $16.79
Unit Price: USD $16.7865
≥1 USD $16.7865
≥10 USD $13.77405
≥100 USD $13.3437
≥500 USD $12.91335
≥1000 USD $12.483
Inventory: 2208
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-TQFP
Number of Pins 48
Weight 137.410139mg
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 48
Type Voice-Band
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Codecs
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Base Part Number TLV320AIC20
Output VOLTAGE
Pin Count 48
Power Supplies 1.83.3V
Number of Channels 2
Interface 2-Wire, I2C, Serial
Max Supply Voltage 1.95V
Min Supply Voltage 1.65V
Data Interface Serial
Sampling Rate 26 ksps
Voltage - Supply, Analog 2.7V~3.6V
Voltage - Supply, Digital 1.65V~1.95V
Number of A/D Converters 2
Analog Input Voltage-Max 2V
Signal to Noise Ratio (SNR) 84 dB
Resolution (Bits) 16 b
Sigma Delta Yes
Number of ADCs / DACs 2 / 2
Filter YES
Dynamic Range, ADCs / DACs (db) Typ 87 / 92
Output Code TWOS COMPLEMENT
S/N Ratio, ADCs / DACs (db) Typ 84 / 92
Input Code TWOS COMPLEMENT
Dimensions
Length 7mm
Width 7mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
