TLV320AIC1103PBS
RoHS
RoHS compliant
RoHS compliantPackage 32-TQFP
Category Integrated Circuits (ICs) / Interface - CODECs
Description
Tape & Reel (TR) TWOS COMPLEMENT Active Nickel/Palladium/Gold (Ni/Pd/Au) codec 15b 2.7V 72.801575mg 16mW
PDF
/
Buying Options
Total Price: USD $6.57
Unit Price: USD $6.57115
≥1 USD $6.57115
≥10 USD $5.3922
≥100 USD $5.2231
≥500 USD $5.05495
≥1000 USD $4.8868
Inventory: 8105
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case 32-TQFP
Surface Mount YES
Number of Pins 32
Weight 72.801575mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
Type PCM
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Codecs
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Base Part Number TLV320AIC1103
Output VOLTAGE
Pin Count 32
Power Supplies 3V
Number of Channels 2
Interface 2-Wire, I2C, Serial
Max Supply Voltage 3.3V
Min Supply Voltage 2.7V
Supply Current-Max 0.007mA
Data Interface PCM Audio Interface
Sampling Rate 8 ksps
Voltage - Supply, Analog 2.7V~3.3V
Voltage - Supply, Digital 2.7V~3.3V
Power Consumption 16mW
Number of D/A Converters 1
Resolution (Bits) 15 b
Sigma Delta Yes
Number of ADCs / DACs 1 / 1
Filter YES
Output Code TWOS COMPLEMENT
Companding Law A/MU-LAW
Input Code TWOS COMPLEMENT
Dimensions
Height 1.2mm
Length 5mm
Width 5mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
