TP3054AN image
Favorite
TP3054AN image
Favorite
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - CODECs
Description COMMERCIAL Through Hole Non-RoHS Compliant CMOS IC CODEC PCM, Filter 0C~70C 19.305mm 5V
PDF
/
Inventory: 1176
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Surface Mount NO

Technical

Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Type PCM, Filter
Terminal Finish NICKEL PALLADIUM GOLD
Technology CMOS
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
JESD-30 Code R-PDIP-T16
Qualification Status COMMERCIAL
Data Interface Serial
Voltage - Supply, Analog ±5V
Sigma Delta No
Number of ADCs / DACs 1 / 1
Filter YES
Companding Law MU-LAW
Neg Supply Voltage-Nom -5V

Dimensions

Height Seated (Max) 5.08mm
Length 19.305mm
Width 7.62mm

Compliance

RoHS Status Non-RoHS Compliant
