ADV611JSTZ image
Favorite
ADV611JSTZ image
Favorite
RoHS
RoHS RoHS compliant
Package 120-LQFP
Category Integrated Circuits (ICs) / Interface - CODECs
Description Tray S-PQFP-G120 Obsolete MATTE TIN codec 8b 5.5V 14mm 0C~70C
PDF
/
Buying Options
Total Price: USD $62.7
Unit Price: USD $62.70475
≥1 USD $62.70475
≥10 USD $51.4501
≥100 USD $49.8427
≥500 USD $48.23435
≥1000 USD $46.62695
Inventory: 1181
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 120-LQFP
Surface Mount YES

Technical

Operating Temperature 0°C~70°C
Packaging Tray
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 120
Type Video
Terminal Finish MATTE TIN
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.4mm
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 120
JESD-30 Code S-PQFP-G120
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Data Interface Serial
Voltage - Supply, Digital 4.5V~5.5V
Resolution (Bits) 8 b
Sigma Delta No

Dimensions

Height Seated (Max) 1.6mm
Length 14mm
Width 14mm

Compliance

RoHS Status ROHS3 Compliant
