CS4272-CZZ
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - CODECs
Description
Tube e3 Active CS4272 codec 114dB 2.37V 900mum 45mA
PDF
/
Buying Options
Total Price: USD $10.16
Unit Price: USD $10.1552
≥1 USD $10.1552
≥10 USD $9.17224
≥100 USD $8.745792
≥500 USD $7.593872
≥1000 USD $7.252608
≥3000 USD $6.612672
Inventory: 1112
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 4.4mm
Length 9.7mm
Height 900μm
Technical
Dynamic Range, ADCs / DACs (db) Typ 114 / 114
Number of ADCs / DACs 2 / 2
Sigma Delta Yes
Resolution (Bits) 24 b
Signal to Noise Ratio (SNR) 114 dB
Number of A/D Converters 2
Voltage - Supply, Digital 3.1V~5.25V
Voltage - Supply, Analog 4.75V~5.25V
Sampling Rate 192 ksps
Data Interface PCM
Number of Bits 24
Nominal Supply Current 45mA
Min Supply Voltage 2.37V
Max Supply Voltage 5.25V
Interface I2C, I2S, SPI, Serial
Number of Channels 1
Power Supplies 3.35V
Qualification Status Not Qualified
Pin Count 28
Base Part Number CS4272
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Consumer ICs
Type Stereo Audio
Termination SMD/SMT
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 1995
Packaging Tube
Operating Temperature -10°C~70°C
Physical
Number of Pins 28
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 16 Weeks
Alternative Model
