CS42325-CQZ
RoHS
/
Package 48-LQFP
Category Integrated Circuits (ICs) / Interface - CODECs
Description
Tray 8542.39.00.01 Obsolete CS4232* codec 24b 3.47V 181.692094mg 24mA
PDF
/
Inventory: 1246
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1.6mm
Technical
Dynamic Range, ADCs / DACs (db) Typ 95 / 100
Number of ADCs / DACs 1 / 2
Sigma Delta Yes
Resolution (Bits) 24 b
Voltage - Supply, Digital 3.13V~3.47V
Voltage - Supply, Analog 3.13V~3.47V
Data Interface Serial
Operating Supply Current 24mA
Interface I2C, SPI, Serial
Supply Voltage-Min (Vsup) 3.13V
Operating Supply Voltage 3.47V
Qualification Status Not Qualified
Pin Count 48
Base Part Number CS4232*
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position QUAD
HTS Code 8542.39.00.01
Type Audio
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Weight 181.692094mg
Number of Pins 48
Package / Case 48-LQFP
Mounting Type Surface Mount
Mount Surface Mount
