TS5V330CDR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Analog Switches - Special Purpose
Description
IC VIDEO SWITCH QUAD SPDT 16SOIC
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.5632
≥1 USD $0.5632
≥10 USD $0.49896
≥100 USD $0.468512
≥500 USD $0.382272
≥1000 USD $0.355062
≥3000 USD $0.302192
Inventory: 1318
Minimum: 1
-
+
Technical Details
Technical
Voltage - Supply, Single (V+) 4V~5.5V
Normal Position NO
Switching BREAK-BEFORE-MAKE
Switch Circuit SPDT
Off-state Isolation-Nom 54 dB
Multiplexer/Demultiplexer Circuit 2:1
On-State Resistance (Max) 10Ohm
Turn-Off Delay Time 5.9 ns
Supply Current-Max (Isup) 0.003mA
Bandwidth 250MHz
Supply Type Single
Turn On Delay Time 6 ns
Operating Supply Current 3μA
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Number of Channels 4
Power Supplies 5V
Operating Supply Voltage 5V
Number of Outputs 8
Pin Count 16
Base Part Number TS5V330
Frequency 250MHz
Terminal Pitch 1.27mm
Supply Voltage 4.5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Multiplexer or Switches
Applications Video
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Resistance 10Ohm
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Bi-Directional, RGB
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 141.690917mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
