TS5USBC402IYFPT
RoHS
RoHS compliant
RoHS compliantPackage 12-XFBGA, DSBGA
Category Integrated Circuits (ICs) / Interface - Analog Switches - Special Purpose
Description
Surface Mount SEPARATE OUTPUT ROHS3Compliant DIFFERENTIAL MULTIPLEXER USB, UART Switch IC 22dB 500mum 1.2GHz 0.07Ohm
PDF
/
Buying Options
Total Price: USD $1.42
Unit Price: USD $1.4168
≥1 USD $1.4168
≥10 USD $1.26368
≥100 USD $1.199616
≥500 USD $0.985336
Inventory: 408
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Thickness 0m
Width 0m
Length 0m
Height 500μm
Technical
Normal Position NO
Voltage - Supply, Single (V+) 2.3V~5.5V
Switch-off Time-Max 1000ns
Switching BREAK-BEFORE-MAKE
On-state Resistance Match-Nom 0.07Ohm
Off-state Isolation-Nom 22 dB
Multiplexer/Demultiplexer Circuit 2:1, 1:2
On-State Resistance (Max) 9Ohm
-3db Bandwidth 1.2GHz
Bandwidth 1200MHz
Input Voltage (Max) 5.5V
Analog IC - Other Type DIFFERENTIAL MULTIPLEXER
Number of Channels 2
Supply Voltage-Max (Vsup) 5.5V
Output SEPARATE OUTPUT
Base Part Number TS5USBC402
Terminal Pitch 0.4mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form BALL
Terminal Position BOTTOM
Applications USB, UART
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Bi-Directional
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 12
Surface Mount YES
Package / Case 12-XFBGA, DSBGA
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
