HV2809K6-G
RoHS
RoHS compliant
RoHS compliantPackage 56-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Analog Switches - Special Purpose
Description
32-CH LOW HARMONIC DISTORTION,HIGH VOLTAGE ANALOG SWITCH56 VQFN 8x8x1.0mm TRAY
PDF
/
Buying Options
Total Price: USD $8.47
Unit Price: USD $8.473457
≥1 USD $8.473457
≥10 USD $7.429701
≥30 USD $6.792945
≥100 USD $6.258594
Inventory: 2505
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Multiplexer/Demultiplexer Circuit 2:1
Dual Supply Voltage 100V
Min Dual Supply Voltage 40V
On-State Resistance (Max) 38Ohm
-3db Bandwidth 50MHz
Max Dual Supply Voltage 200V
Turn-Off Delay Time 30 μs
Supply Type Dual
Voltage - Supply, Single/Dual (±) 40V~200V ±40V~160V
Turn On Delay Time 30 μs
Throw Configuration SPST
Max Supply Current 10μA
Nominal Supply Current 10μA
Operating Supply Current 14mA
Analog IC - Other Type DIFFERENTIAL MULTIPLEXER
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Number of Channels 32
Polarity Non-Inverting
Base Part Number HV2809
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
HTS Code 8542.39.00.01
Applications Ultrasound
Resistance 38Ohm
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e4
Published 2013
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Weight 191.387631mg
Package / Case 56-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Factory Lead Time 17 Weeks
