SN74HC4851DRE4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Analog Switches, Multiplexers, Demultiplexers
Description
GULL WING Surface Mount ROHS3Compliant SEPARATE OUTPUT Switch IC 22pF 195Ohm 6V 90ns
PDF
/
Buying Options
Total Price: USD $0.97
Unit Price: USD $0.96805
≥1 USD $0.96805
≥10 USD $0.7942
≥100 USD $0.7695
≥500 USD $0.7448
≥1000 USD $0.7201
Inventory: 47567
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Resistance 195Ohm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Multiplexer or Switches
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Base Part Number 74HC4851
Output SEPARATE OUTPUT
Pin Count 16
Number of Channels 1
Number of Circuits 1
Max Supply Voltage 6V
Min Supply Voltage 2V
Operating Supply Current 2μA
Nominal Supply Current 2μA
Propagation Delay 25 ns
Turn On Delay Time 95 ns
Logic Function Demultiplexer, Multiplexer
Input Voltage (Max) 6V
Number of Inputs 8
Supply Type Single
Supply Current-Max (Isup) 0.04mA
Turn-Off Delay Time 95 ns
On-State Resistance (Max) 195Ohm
Multiplexer/Demultiplexer Circuit 8:1
Current - Leakage (IS(off)) (Max) 200nA
Channel Capacitance (CS(off), CD(off)) 22pF
On-state Resistance Match-Nom 2Ohm
Switch Time (Ton, Toff) (Max) 78ns, 78ns
Channel-to-Channel Matching (ΔRon) 3 Ω
Switching BREAK-BEFORE-MAKE
Switch-on Time-Max 90ns
Switch-off Time-Max 90ns
Voltage - Supply, Single (V+) 2V~6V
Normal Position NC
Signal Current-Max 0.05A
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
