CD4097BE
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Interface - Analog Switches, Multiplexers, Demultiplexers
Description
Non-Inverting Through Hole ROHS3Compliant Demultiplexer Multiplexer Switch IC 0.2pF 35pF 240Ohm 18V 60ns
PDF
/
Buying Options
Total Price: USD $5.31
Unit Price: USD $5.30765
≥1 USD $5.30765
≥10 USD $4.3548
≥100 USD $4.21895
≥500 USD $4.0831
≥1000 USD $3.94725
Inventory: 1178
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP (0.600, 15.24mm)
Number of Pins 24
Weight 3.735305g
Technical
Operating Temperature -55°C~125°C TA
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Resistance 240Ohm
Subcategory Multiplexer or Switches
Max Power Dissipation 500mW
Voltage - Supply, Single (V+) 3V~18V
Channel-to-Channel Matching (ΔRon) 5 Ω
On-state Resistance Match-Nom 15Ohm
Channel Capacitance (CS(off), CD(off)) 0.2pF 35pF
Current - Leakage (IS(off)) (Max) 100nA
Multiplexer/Demultiplexer Circuit 8:1
Input Capacitance 5pF
On-State Resistance (Max) 240Ohm
Turn-Off Delay Time 440 ns
Supply Current-Max (Isup) 3mA
Bandwidth 20MHz
Supply Type Single
Number of Inputs 16
Logic Function Demultiplexer, Multiplexer
Turn On Delay Time 650 ns
Quiescent Current 80nA
Propagation Delay 60 ns
Number of Bits 8
Power Dissipation 500mW
Nominal Supply Current 5μA
Operating Supply Current 80nA
Analog IC - Other Type DIFFERENTIAL MULTIPLEXER
Min Supply Voltage 3V
Max Supply Voltage 18V
Number of Circuits 2
Number of Channels 1
Polarity Non-Inverting
Pin Count 24
Base Part Number CD4097
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
