MAX4601CAE image
Favorite
MAX4601CAE image
Favorite
RoHS
/
Package 16-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Interface - Analog Switches, Multiplexers, Demultiplexers
Description Surface Mount Non-RoHS Compliant Obsolete SPST - NC Switch IC 55pF 55pF 100mOhm 120pC 4.5V~36V ±4.5V~20V
PDF
/
Buying Options
Total Price: USD $6.53
Unit Price: USD $6.534264
≥1 USD $6.534264
≥10 USD $6.164391
≥100 USD $5.81547
≥500 USD $5.486295
≥1000 USD $5.175748
Inventory: 5519
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

Crosstalk -59dB @ 1MHz
Channel-to-Channel Matching (ΔRon) 100mOhm
Charge Injection 120pC
Switch Time (Ton, Toff) (Max) 250ns, 350ns
Switch Circuit SPST - NC
Channel Capacitance (CS(off), CD(off)) 55pF 55pF
Current - Leakage (IS(off)) (Max) 500pA
Multiplexer/Demultiplexer Circuit 1:1
On-State Resistance (Max) 2.5Ohm
Voltage - Supply, Single/Dual (±) 4.5V~36V ±4.5V~20V
Number of Circuits 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature 0°C~70°C TA

Physical

Supplier Device Package 16-SSOP
Package / Case 16-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
