MAX328CWE
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Analog Switches, Multiplexers, Demultiplexers
Description
GULL WING Surface Mount Non-RoHS Compliant SINGLE-ENDED MULTIPLEXER Switch IC 84dB 1.8pF 8pF 70Ohm 2pC
PDF
/
Inventory: 3246
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Channel-to-Channel Matching (ΔRon) 70 Ω
Charge Injection 2pC
Switch Time (Ton, Toff) (Max) 1.5μs, 1μs
On-state Resistance Match-Nom 30Ohm
Channel Capacitance (CS(off), CD(off)) 1.8pF 8pF
Current - Leakage (IS(off)) (Max) 10pA
Off-state Isolation-Nom 84 dB
Multiplexer/Demultiplexer Circuit 8:1
On-State Resistance (Max) 3.5kOhm
Neg Supply Voltage-Nom (Vsup) -15V
Voltage - Supply, Single/Dual (±) 10V~30V ±5V~18V
Analog IC - Other Type SINGLE-ENDED MULTIPLEXER
Number of Circuits 1
Number of Channels 8
Pin Count 16
Time@Peak Reflow Temperature-Max (s) 20
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Terminal Finish TIN LEAD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
