MAX4712CUE
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Analog Switches, Multiplexers, Demultiplexers
Description
GULL WING Surface Mount Not Qualified Non-RoHS Compliant Switch IC 59dB 8pF 8pF 200m Ohm 25pC
PDF
/
Buying Options
Total Price: USD $69.51
Unit Price: USD $69.51055
≥1 USD $69.51055
≥10 USD $67.3379
≥100 USD $65.1662
≥500 USD $62.99355
≥1000 USD $56.4775
Inventory: 1226
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 2004
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn85Pb15)
Additional Feature CAN ALSO OPERATE FROM SINGLE SUPPLY OF 2.7V TO 11V
Subcategory Multiplexer or Switches
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 0.65mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number MAX4712
Output SEPARATE OUTPUT
Pin Count 16
JESD-30 Code R-PDSO-G16
Qualification Status Not Qualified
Power Supplies 3/5/+-5V
Number of Channels 1
Number of Circuits 4
Voltage - Supply, Single/Dual (±) 2.7V~11V ±2.7V~5.5V
Neg Supply Voltage-Nom (Vsup) -5V
On-State Resistance (Max) 25Ohm
Multiplexer/Demultiplexer Circuit 1:1
Off-state Isolation-Nom 59 dB
Current - Leakage (IS(off)) (Max) 500pA
Channel Capacitance (CS(off), CD(off)) 8pF 8pF
On-state Resistance Match-Nom 0.2Ohm
Switch Circuit SPST - NO
Switch Time (Ton, Toff) (Max) 125ns, 80ns
Charge Injection 25pC
Channel-to-Channel Matching (ΔRon) 200m Ω
Crosstalk -87dB @ 1MHz
Switching BREAK-BEFORE-MAKE
Switch-on Time-Max 125ns
Switch-off Time-Max 80ns
Normal Position NO
Dimensions
Height Seated (Max) 1.1mm
Length 5mm
Compliance
RoHS Status Non-RoHS Compliant
