OP295A image
Favorite
RoHS
RoHS RoHS compliant
Package T 1 3/4
Category Optoelectronics / Infrared, UV, Visible Emitters
Description EMITTER IR 890NM 150MA T 1 3/4
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.7744
≥100 USD $0.75504
≥500 USD $0.726
≥1000 USD $0.70664
≥3000 USD $0.68728
Inventory: 1129
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 5.97mm
Length 5.97mm
Height 8.64mm

Technical

Head Diameter 4.95 mm
Peak Wavelength 890 nm
Number of LEDs 1
Current - DC Forward (If) (Max) 150mA
Wavelength 890nm
Reverse Voltage 5V
Fall Time (Typ) 250 ns
Forward Voltage 4V
Rise Time 500ns
Test Current 10mA
Peak Pulse Current 5A
Max Reverse Leakage Current 10μA
Lens Style Circular, Round
Forward Current 1.5A
Viewing Angle 20°
Voltage - Forward (Vf) (Typ) 4V
Power Dissipation 1.11kW
Number of Elements 1
Lead Length 19.05mm
Lead Pitch 2.54mm
Depth 5.97mm
Orientation Top View
Max Power Dissipation 333mW
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Type Infrared (IR)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2017
Packaging Bulk
Operating Temperature -40°C~100°C TA

Physical

Housing Material Plastic
Number of Pins 2
Package / Case T 1 3/4
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 8 Weeks
