RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / Infrared, UV, Visible Emitters
Description
EMITTER IR 890NM 100MA RADIAL
PDF
/
Buying Options
Total Price: USD $12.54
Unit Price: USD $12.540821
≥1 USD $12.540821
≥200 USD $5.004775
≥500 USD $4.836724
≥1000 USD $4.754011
Inventory: 1182
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 2.41mm
Technical
Radiant Intensity (Ie) Min @ If 1.2mW/cm2 @ 50mA
Current - DC Forward (If) (Max) 100mA
Wavelength 890nm
Reverse Voltage 2V
Forward Voltage 1.8V
Test Current 50mA
Forward Current 100mA
Viewing Angle 24°
Voltage - Forward (Vf) (Typ) 1.8V
Power Dissipation 150mW
Number of Elements 1
Depth 2.41mm
Orientation Top View
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Type Infrared (IR)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2016
Packaging Bulk
Operating Temperature -65°C~125°C TA
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
